Onyx Gi5
Onyx Gi5
Couldn't load pickup availability
- Ultra-Portable: At almost the size heigh of an egg & weighing little as .21Kg, Onyx Gi5 can be easily placed in your pocket or bag with no hassle. There's also no need for internet when you use 1gb + 32gb storage or connect external hard drives.
- 1080p Quality: The Keplar mini projector includes powerful processing that packs a stunning 1080p resolution up to a 100” screen & contains 100 Ansi Lumens that casts a bright yet smooth quality.
- Silent Ninja: 1*1w internal speakers produces sufficient sound with clear quality, in addition to processing a noiseless fan
- Packing Great Power: 3300MAH built-in battery ensures you can enjoy a longer playtime of 2.0 hours & charges faster than it burns batter within 65 minutes while also can be a power bank for your smartphone.
- Android 7.1.2 OS: Get all your entertainment through over 4,000 applications.
- Note: Copyrighted content from Netflix, Amazon Prime Videos, and similar provided services CAN NOT be mirrored or screencast for legal reasons.
- Shipping Note: Shipping begins within 3-5 days.
Product Features
Overview
Rockchip 4128 CPU
The RK4128 CPU provides stable and robust processing to support 1080p video decoding.
Automatic Keystone Correction
Set any angle with keystone correction technology and instantly snap the image screen into position.
Stable and Smooth Bluetooth
Bluetooth 4.2 connection goes up to 10 meters with various compatible devices.
Projection Distance
With a 1.35.1 short throw ratio, you can always get a massive screen in a short projection distance.
Magic Touch
Intuitive and touch-sensitive, you can control the projector only with one finger on the touch panel, navigate seamlessly through media apps, and more with drag and click.
Ultra-Long Lifespan
The Onyx Gi5 utilizes a multi-layer led transmission lens that gives a lamp life of up to 30,000 while keeping it stunning and clear quality during Lifesource. 4 hours of playtime daily can be used for the next ten years while consuming less power than a large majority of projectors.
Multiple ways to connect
Stream or play any content through various methods such as Bluetooth, airplay, share, screen mirroring through Wi-Fi, or using a USB or HDMI port, no matter the device you choose.
Specification
Display
Product Classification: Smart Mini Projector
Projection Technology: American DLP Technology
Display Chip: 0.20” DMD
Brightness: 100 ANSI Lumens
Resolution: 1920 × 1080 pixels
Lamp Life: 30,000 Hours (10yrs)
Light Source: LED
Operation: Touch screen Panel
Projection
Keystone Correction: Horizontal: Manual, Vertical: Auto ±40°
Lens Focus: Manual
Projection Ratio: 1.2: 1
Aspect Ratio: 16:9
Projection Mode: Front, Rear, Front Ceiling, Rear Ceiling
Throw Ratio: 10-100 inches
Throw Distance: 1.0-3.0 Meters
System
RAM: 1GB
Flash Storage: 32GB
System: Android 9.0
Smart Mirroring Display: support Airplay/Miracast
CPU: K4128
Connectivity
Output Port: Headphone × 1 (3.5mm)
WiFi: Dual-band 2.4/5G
Bluetooth: 4.2
USB : HDMI input
Electrical
DC Input Power: DC 5V 3A
Power Consumption: 10W
Internal Battery Capacity: 3300MAH
Battery Lifetime: Up to 1.5H
Speaker: 1WX1
MeasurementsProduct Size (H × W × D) ：60×60×58mm
Product Weight：210g
What's in the Box
Tripod: x 1
Manual: x 1
Power Plug: x 1
Remote Control: x 1
HDMI Cable: x1
FAQ
Display
(Q)How do I adjust the focus?
(A) Slide the pinion on the left device until you see a crystal-clear image.
(Q) How do I use keystone correction?
(A) Onyx supports both automatic (vertical ±40°) and manual (horizontal ±40°) keystone correction. If you have the projection on an uneven surface, then getting a flat screen will be challenging, but you can manually adjust the screen 1. settings 2. scroll down to auto-correction 3. select manual keystone correction and adjust the screen if you also want you can initial angle correction (this requires horizontal surface).
(Q) How can I make the quality crystal clear in gaming or videos
(A) head over to settings, go to 2. common settings, select brightness, and adjust to your requirements.
(Q) Can I use the Onyx Gi5 during the Daytime
(A) Using projection in a dark environment or soft lighting is highly recommended to bring out clear quality at 100 Ansi Lumens.
Compatibility
(Q) How Do I connect Onyx Gi5 to Wi-Fi?
(A) 1. Select “settings,” and then select “WIFI”, click the ON/OFF button to turn on/off WIFI. 2 Then choose WIFI and enter the password to connect network.
(Q) How Do I connect my speaker or headphones to the Onyx Gi5?
(A) Select “Settings” Bluetooth, then turn on “Bluetooth”, then click “projector,” and press the “ok” key on the device to rename the Bluetooth. Select “available equipment” and choose an available device to connect.
(Q) How to screen share on (android)?
(A) Android smartphone and projector should connect with the same WIFI 2. find screen sharing functions in the settings, then open it 3. open the projector and find Wi-Fi display or Miracast in intelligent apps. 4. click “search”, it will search for a smartphone, and click “agree” in the pop-up.
(Q) How to Eshare for android, IOS, & windows?
(A) 1. connector to the same network to connect to the projector 2. visit Eshare download link or scan the QR code with a cellphone to download and install the app 3. open Eshare, then click the device name.
(Q) How to Screen Share for iPhone?
(A) slide the iPhone screen from bottom to top, click airplay mirror, and the chosen device in the list to achieve sharing screen with iPhone
(Q) Can I connect Onyx Gi5 to any gaming console?
(A) You can enjoy any gaming console connected through HDMI Port from Xbox, Nintendo, PlayStation, and many more...
(Q) Can your airplay or Chromecast Netflix from your mobile device?
(A) No, paid streaming apps such as Netflix, Prime Video, Hulu, and Disney+ have copyright protection that prevents mirroring from mobile devices due to policies enacted and enforced by content owners.
(Q) Can I install any apps on the Keplar?
(A) 1. Go to the Google Play store, then search, download and install the app. 2. After installing the app, you can click "customize channel" and choose whether to let the app appear on the launcher.
Function & Operation
(Q) Will the Onyx Gi5 get overheated?
(A) The outer body is designed with air ducts and one a kind of fan to make sure the mini projector efficiently dissipates heat for several hours of use without being overheated.
(Q) what does the mouse button on the control do?
(A) The mouse icon Is a pointer you can use to navigate as you would on a computer or laptop. To increase the pointer speed, 1. go to setting 2. scroll down to other settings 3. select pointer speed and decide how fast you would like it to operate.
(Q) Can I charge my mobile device through the Onyx Gi5?
(A) You can charge your mobile device through the USB port.
(Q) Do I need to replace the led Lamp on the Projector?
(A) The projector uses a Led Lamp instead of a Bulb, so during the projector's lifetime, you can use 30,000 hours, equivalent to 10 years (4 hours of playtime a day) without worrying about changing the Lamp.
(Q) How Do I know If the Keplar is charging?
(A) Plug in the charger in the projector, and by the power button, when you see a red light, the projector is charging.
(Q) does a low battery affect how the projector functions?
(A) Image quality will darken, or you might be returned to the homepage; this is a sign that you need to charge the Keplar to continue projection at high performance.
